The world s single largest loop reactor was successfully hoisted

On June 28 and July 8, two sets of the world's largest single set of 500,000 tons/year high-density polyethylene plant loop reactor contracted by Sinopec Shipping Company at Tianjin Petrochemical Nangang Ethylene Project were successfully transported and hoisted bit.

The height of the loop reactor equipment is 76 meters, and the module weight is 653 tons. The innovative six-pipe integral frame and the "Japanese-shaped" modular transportation and hoisting new technology adopt the 2000-ton main crane + 800-ton sliding tail delivery method. Equipped with a 1000-ton adjustable ring pipe special balance beam independently developed and designed to complete the equipment hoisting, it is the largest single ring pipe reactor in the world with an overall modular design, manufacturing, transportation and hoisting.

Sinopec Shipping Company adheres to the "integrated hoisting and transportation" management mode, implements "door-to-door" service, independently compiles the integrated transportation and hoisting plan, and is responsible for the entire process of implementation, receiving goods from the manufacturing plant and transporting them to the dock Carry out shipment, transport to Tianjin Nangang Wharf by sea, unload the ship with its own Godhoff 60-axis SPMT axis transport vehicle and transport it to the construction site to successfully complete the hoisting, creating a precedent for the overall manufacturing, transportation, and hoisting integration of the loop reactor. The hoisting period of the two loop reactors was reduced from 60 days to 4 days, which greatly shortened the construction period and left a strong mark in the field of petrochemical engineering construction.

As the only professional service provider of hoisting and transportation integration in Sinopec, Sinopec Shipping Company has always carried forward the style of "iron army" and the spirit of "bright sword", with "safety and high quality" as the core, and "great improvement, great development, "Great breakthrough" is the purpose, to overcome difficulties and take responsibility. In the future development, Sinopec Shipping Company will continue to pursue excellence and contribute to the construction of the national energy industry! (Qu Zhaogui, correspondent Liang Yiyu, Wang Zhe, Wang Yubo)
